West Midlands Metro Birmingham
Copyright
These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.
current and upcoming projects
-
Wednesbury to Brierley Hill Metro Extension
Neubaustrecke für die zukünftige Linie 2 von Wednesbury nach Brierley Hill.
drawn on the trackmap | website-
Phase 1: Wednesbury – Dudley
in Bau | proposed inauguration: August 2026 -
Phase 2: Dudley – Brierley Hill
in Bau | proposed inauguration: 2028
-
-
Eastside Metro Extension
Neubaustrecke von Bull Street bis Birmingham International Airport und Birmingham HS2 Interchange.
drawn on the trackmap | website-
Phase 1, 1. Abschnitt: Bull Street – Millenium Point
fertiggestellt | inauguration: 05.04.2026 -
Phase 1, 2. Abschnitt: Millenium Point - Digbeth
in Bau | proposed inauguration: Frühestens 2029 -
Phase 2: Digbeth – Airport
Idee | proposed inauguration: noch offen
-
Short-time construction works with no effect on the trackmap are not listed here.
| network data | |
inauguration: | 30.05.1999 |
track gauge: | 1435 mm |
overhead wiring: | 750 VDC |
operator: | Midland Metro Ltd |
owner: | Transport for West Midlands |
network, total length: | 24 km |
stops: | 35 |
top speed: | 70 km/h |
traffic direction: | ⇄ |
| rolling stock (2026) | |
trams: | 42 |
- 03.05.2026
New line to Millennium Point inaugurated, New line to Brierley Hill updated. - 04.11.2023
New line to Wolverhamption Station inaugurated. - 23.07.2022
Line extension to Edgbaston Village inaugurated. - 19.03.2022
New trackmap: West Midlands Metro:
Found a mistake?
You have found a mistake in the map or you know a current change? Here you can directly advise it. This will be considered in the next update.
Updates of the maps will be done about every month. You will get a message when the update is done.
