  • Current tramway trackmap

    track network of the Carris in Lisbon.

    show trackmap trackmap as pdf trackmap as svg key

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

  • Ausführliche Definitionen der im Gleisplan verwendeten Symbole und Darstellungen.

    • current and upcoming projects

      Short-time construction works with no effect on the trackmap are not listed here.

    • Avenida Dom Carlos I

      Streckensperrung für den Bau der U-Bahn.
      in Bau | proposed inauguration: 2024
      drawn on the trackmap

    profile

    network data
    inauguration:
    		17.11.1873
    operator:
    		Carris
    track gauge:
    		900 mm
    overhead wiring:
    		600 VDC
    network, total length:
    		25 km
    rolling stock (2017)
    articulated trams:
    		10
    old trams:
    		47
    therof bi-directional trams:
    		2

    last updates

    • 23.02.2024
      New stops at Rua Prata.
    • 05.03.2023
      Track connection at Santos under construction.
    • 23.06.2018
      The single track route at São Tomé was replaced by a double track.
    • 28.04.2018
      The 1995 shut down line 24E is back in operation.
    • 05.01.2018
      Map completely revised and updated.
    • 31.05.2017
      Extensive reconstructions in the Corpo Santo area.
