current trackmaps

  • Current trackmap

    Complete network in Kassel and surrounding.

    show trackmap trackmap at pdf trackmap at svg key

  • share

  • Copyright

    These drawings are protected by copyright. A further use is possible by application of the Creative-Commons-Lizenz by-nc-sa.

    • weitere Pläne

  • network overview

    All routes shown in map and aerial view
    network overview

    Central station

    Situation before the reconstruction 2005.
    trackmap

    • last updates

    • 01.12.2022
      Track crossing in Kaufungen removed.
    • 12.10.2021
      Route Mattenberg - VW-Werk Schleife permanently closed.
    • 25.11.2018
      Several stops accessible reconstructed.
    • 27.03.2018
      Several line changes.
    • 13.05.2017
      Route to VW-Werk Schleife closed.
    • 03.03.2017
      Operation times added and some minor changes.

    profile

    network data
    inauguration:
    		09.07.1877
    operator:
    		KVG
    network, total length (2012):
    		51,2 km
    track gauge:
    		1435 mm
    overhead wiring:
    		600 VDC
    stops:
    		127
    rolling stock (2012)
    trams:
    		119
    therof Regio-Trams (600 VDC / 15 kV):
    		18
    therof Regio-Trams (600 VDC / Diesel):
    		10
    oldtimer trams:
    		3
    units needed for regular service:
    		82
    therof Regio-Trams (600 VDC / 15 kV):
    		14
    therof Regio-Trams (600 VDC / Diesel):
    		9
    partly estimated
